VCI Oils - Dry Type 1003 XR

Save 18%

Quantity: 26 Liters
Sale priceRs. 4,904.00 Regular priceRs. 5,980.00

Shipping calculated at checkout


Exports of automotive components is a very critical task which requires specialized Rust Preventive Packaging schemes in synergism with highly effective rust preventive oils.

RUSTX oils contain VCI chemicals, which work in contact phase as well as in the vapor phase and protect components by its dual action.

RUSTX – 1003 XR is used where medium to long term prevention is required along with very slight lubrication on the parts.

 The VCI action of the oil makes it suitable for spraying within hollow equipment such as boilers, heat exchangers, reactors, storage tanks, pipes etc. The VCI fraction evaporates and reaches hard to reach surfaces where the direct oil spray cannot reach and protects the equipment from corrosion.

 All RUST-X rust preventive oils are Barium & Heavy Metal Free


  • Slightly lubricating oil film
  • Good coverage due to low viscosity- high floatability & high penetration properties
  • Less consumption due to thin film
  • Allow 2-10 minutes drain and drying time depending upon product requirement
  • Long Term Corrosion Prevention
  • Quick Drying - Dries within 10-15 min
  • Excellent protection against acidic & saline environments
  • Non Sticky washable film
  • Paintable in paint line


Physical Properties

Test Method




Amber Clear

Viscosity @ cSt @ 40°C

ASTM D 445

4-6  cSt

Specific Gravity

ASTM D 1298

0.78 - 0.83

Dry Film Thickness

IS 2074

3-4 microns

Flash Point (before application)

ASTM D  92


Volatile by % (by weight)


60-70 %

Coverage (sq m/Lt)



Pour Point


Below -5oC

Saponification  value (mg KOH/gm)



Salt Spray Protection

ASTM B 117

96 hours+

Salt Spray in VCI

ASTM B 117

720 hours+

Condensation Test

DIN 50017 KFW

>60 cycles

Humidity Chamber

ASTM D 1748

720 hours+

Dry Time


15-30 minutes
